3-48 Section 3-6 - System Configuration
Note: When a system’s Back End is upgraded to Pentium 4, in future the BEP should only be replaced
with a Pentium 4-type BEP. See Chapter 8 - Replacement Procedures and Chapter 9 - Renewal
Parts for more details.
Table 3-17 Recommended Vivid™ 3 Hardware Configurations - RFI Models
Item BT03 Vivid™ 3
ECG
Second Re
Image Port
No board
Front Board
V7-3 (TR-V4) or V7-2 (TR-V4
Ex Keyboard
Revision 4
MUX Board
V2
Sound Board
Ver. 3
PCI (Frame) Grabber
Falcon
Network Board
Intel EtherExpr
UPS
PowerCard 450
VIC
V1 (PC VIC)
Number of Fans
5
Table 3-18 Recommended Vivid™ 3 Hardware Configurations - RFT Models
Item BT03
Vivid™ 3
BT03
Pro
ECG
Second Re Second Re
Image Port
Revision E8/F8 Revision E8/F8
Front Board
V7-3 (TR-V4) or V7-2 (TR-V4 V7-3 (TR-V4) or V7-2 (TR-V4)
Ex Keyboard
Revision 4 Revision 4
MUX Board
V2 V2
Sound Board
Ver. 3 Ver. 3
PCI (Frame) Grabber
No board No board
SCSI Board
AHA-29160N AHA-29160N
Network Board
Intel EtherExpr Intel EtherExpr
UPS
a
a. optional
PowerCard 450 PowerCard 450
VIC
V1 (PC VIC)
b
b. valid only for Pentium 4; when a machine is based on Pentium III, use V0 (external).
V1 (PC VIC)
b
Number of Fans
5 5
