GE Vivid 3

GE MEDICAL SYSTEMS
D
IRECTION 2300164-100, REVISION 7 VIVID™ 3 PRO/VIVID™ 3 SERVICE MANUAL
Chapter 3 - Installation 3-51
3-7-2-2 Local Network Connection to EchoPAC PC Workstation
Figure 3-31 Local Network Connection
3-7-2-3 Hospital Network Connection to EchoPAC PC Workstation
Figure 3-32 Hospital Network Connections
See the EchoPAC PC Service Manual (Part Number EP091298) for details about the EchoPAC PC,
and the required set-up procedures.
EchoPAC PC
Vivid7
Do not use the fifth connector and the
switch can be in any position,
Use only Standard non-crossed Ethernet
cabling.
Vivid3
Using standard non-crossed cables and MDI
switch set to position =HUB, connect like this.
Wall connection
EchoPAC PC
or Vivid7
Vivid3
