Chapter 5 - Components and Function (Theory) 5-33
Table 5-6 BEP Motherboard Layout BT02/BT03 - Legend to Figure 5-23
Jumpers Description Default Setting
BT1 CMOS Clear Open (Disabled)
JP1 Front Side Bus Speed Pins 1-2 (Auto)
JP2 Watch Dog Enable Open (Disabled)
JP3 Speech Output Select Pins 1-2 (Speaker)
JPUSB USB0/1 Wake Up Pins 1-2 (Disabled)
JPWAKE Keyboard Wake-Up Pins 1-2 (Disabled)
Connectors
Description
CD1 Audio CD Input (large connector)
CD2 Audio CD Input (small connector)
Chassis Fan1/2 Chassis Fan Header
COM1/COM2 COM1/COM2 Serial Port Connector/Header
CPU Fan CPU Fan Header
DIMM1/2 Memory (DIMM) Slots
Ethernet LAN (Ethernet Port)
Game Port Game Port
J1
a
a. P4SGA only
4xAGP
J5 Floppy Disk Drive Connector
J6/J7 IDE #1/#2 Hard Disk Drive Connectors
J15 Parallel Printer Port
J17 PS/2 Keyboard/Mouse
J21 ATX 12V Power Connector (20-pin)
J24
b
b. The 4-pin connector at J24 must be connected to meet the safety requirements
of the ATX 12V specifications.
ATX 12V Power Connector (4pin)
JA1 SPDIF Connector
JF1, JF2 Front Control Panel
JL1 Chassis Intrusion Header
JOH 1 Overheat LED
JWOR1 Wake-On-Ring Header
LE2 5v Standby Warning LED
LINE IN Audio In Connector
LINE OUT Audio Out (Speaker) Connector
MIC Microphone Input
USB2/USB3 Universal Serial Bus Port 2/3
USB4/USB5 Universal Serial Bus Port 4/5
WOL Wake-On-LAN
