GE Vivid 3

GE MEDICAL SYSTEMS
D
IRECTION 2300164-100, REVISION 7 VIVID™ 3 PRO/VIVID™ 3 SERVICE MANUAL
5-40 Section 5-1 - Overview
5-5-16-2 PAL
5-5-16-3 NTSC
Table 5-7 PAL Video Specifications
Horizontal Timing
Horizontal Total (HT)
us 944 pixels
Horizontal Start (HS)
us 152 pixels
Horizontal Active (HA)
us 768 pixels
Pixel Clock Freq
14.7 MHz (PAL)
Vertical Timing (Interlaced)
Vertical Start (VS)
53 Lines / field
Active Lines (VA)
Lines / frame (=PAL standard)
Total Lines (VT)
625 Lines / frame (=PAL standard)
Frame Rate
25Hz (=PAL standard)
Table 5-8 NTSC Video Specifications
Horizontal Timing
Horizontal Total (HT)
us 780 pixels
Horizontal Start (HS)
us 118 pixels
Horizontal Active (HA)
us 640 pixels
Pixel Clock Freq
12.272725 MHz (NTSC)
Vertical Timing (Interlaced)
Vertical Start (VS)
17 Lines / field
Active Lines (VA)
(525 - 17) Lines / frame (=NTSC standard)
Total Lines (VT)
525 Lines / frame (=NTSC standard)
Frame Rate
30Hz (=NTSC standard)
