7-10 Section 7-3 - Performing Front End (FE) Diagnostics
The FE Diagnostics dialog box includes the following options:
Table 7-2 FE Diagnostics Dialog Box Options
Option Description Comments
Data Flow
Map
Displays a graphic representation of the Vivid™
3 data flow. The functionality of each button in
this area corresponds to that of the tab of the
same name in the lower portion of the dialog
box. Each button or tab enables you to select
and perform the FE diagnostic tests by
trackballing to the required button or tab and
pressing Select.
Each button has an LED that indicates the
following by its color:
• Green: The test has been completed and no
problems were identified.
• Red: Problems were identified during the
performance of the test.
• Yellow: The test is in progress.
Test
Description
Area
Displays a description of the selected diagnostic
test.
Test Area Displays the buttons that enable you to perform
diagnostic tests.
Each button has an LED that indicates the
following by its color:
• Green: The test has been completed and no
problems were identified.
• Red: Problems were identified during the
performance of the test.
• Yellow: The test is in progress.
Comment
Area
Displays instructions during the test, as well as
test status and result messages.
The following messages are displayed:
• Test status: For example, Ready for test or
Complete
• Instructions: During the course of a
diagnostic test, any instructions to the user
are displayed in the Comment area
• Test results: For example, Pass or Fail.
Tabs Enable you to select and perform the FE
diagnostic tests.
H/W Report
Button
Displays hardware and software version
information, as described in
Chapter 1 - Introduction.
Current
Report
Button
Displays the saved error log, as described in the
Common Service Interface section, on page 7-84.
Close Button Closes the FE Diagnostic dialog box and
re-displays the Diagnostic menu.
