GE MEDICAL SYSTEMS
D
IRECTION 2300164-100, REVISION 7 VIVID™ 3 PRO/VIVID™ 3 SERVICE MANUAL
Chapter 7 - Diagnostics/Troubleshooting 7-43
7) Check the test result message and proceed as follows:
• If one or more relays were identified as bad, trackball to Save Report and press Select, and
contact a GE Medical Systems service representative.
• If no relays were identified as bad, mark the channels suspected as being bad as follows:
• Trackball to the channel in the Display area and press Select.
• Trackball to the Mark bad channel checkbox and press Select. Repeat as required to
mark additional channels.
• Trackball to Save Report and press Select, and contact a GE Medical Systems service
representative.
• If no errors were identified, proceed with the next test.
• If no errors were identified but the problem persists, contact your local GE Medical Systems
field engineer for assistance.
• If errors were identified but the results were marginal, perform calibration, as described in the
Calibration section, on page 6-14, and then repeat the test.
• If errors were identified and the results were not marginal, verify that all image port and PCI
bridge cables are connected and functioning properly, as described in Chapter 5 - Components
and Function (Theory)
. If the problem persists, contact your local GE Medical Systems field
engineer for assistance.
8) Trackball to the Exit button and press Select. If required, repeat this test with a different pulser.
