GE HEALTHCARE - KRETZTECHNIK VOLUSON® 730EXPERT (BT03)
D
IRECTION 105899, REVISION 3 DRAFT (APRIL 29, 2008) SERVICE MANUAL
3-38 Section 3-7 - Printer Installation
3-7-4-2 UP-D21MD / UP-D23MD - Printer Settings
1.) Call up the ‘Printer Properties’; operation see: Section 3-7-4 "Adjustment of Printer Settings" .
2.) Select the
PAPER page and select:
- Paper Size: UPC-21L (large) / UPC-21S (small)
- Orientation: Landscape (recommended when using large paper size)
- High Speed (check mark on)
NOTICE
!! NOTICE:
Settings for Paper Size MUST match with the used Paper (large/small) and also the right color ink
cartridge has to be used. Otherwise you will get an error message at printing.
Figure 3-44 Paper page
