GE Voluson E8 Expert - Connecting the LCD Monitor

GE HEALTHCARERAFT VOLUSON E8 / VOLUSON E6
D
IRECTION KTD102576, REVISION 7 DRAFT (AUGUST 23, 2012) SERVICE MANUAL
3-10 Section 3-5 - Connection of Auxiliary Devices
3-5-1 Connecting the LCD Monitor
NOTE: The LCD monitor comes pre-installed with the system.
Figure 3-5 Connection Scheme - LCD Monitor
Console back
