11. Easy Guide to M-Mode and Anatomical M-Mode

 Press M-Mode hard key

 After pressing M-Mode use the trackball to position the cursor

 Use the side keys (labeled 2D/M Run on the screen) next to the trackball to active the trace

 Adjust the speed or invert if desired

 On freeze the calc package will be activated

 M Sub menu on touch screen – select display size

Page 25 of 37
