GE WavePro WPF-08 User Manual

Trip Unit and Rating Plug Catalog Numbers
27
Table 27.3 WavePro™ Breaker Power+ and MicroVersaTrip Plus / PM Rating Plug Catalog Numbers
Breaker Frame Current Sensor Rating Plug Power+ Rating Plug Power+ Rating Plug Power+ Rating Plug MicroVersaTrip Plus/PM
Size (Amps) (Amps) (Amps) w/o GF with GF with Defeatable GF Rating Plug
60 N/A N/A N/A TR1B60
80 TR1C80 TR1C80GF TR1C80GFD TR1B80
150 100 TR1C100 TR1C100GF TR1C100GFD TR1B100
125 TR1C125 TR1C125GF TR1C125GFD TR1B125
150 TR1C150 TR1C150GF TR1C150GFD TR1B150
150 N/A N/A N/A TR4B150
200 TR4C200 TR4C200GF TR4C200GFD TR4B200
400
225 TR4C225 TR4C225GF TR4C225GFD TR4B225
800 250 TR4C250 TR4C250GF TR4C250GFD TR4B250
300 TR4C300 TR4C300GF TR4C300GFD TR4B300
400 TR4C400 TR4C400GF TR4C400GFD TR4B400
300 N/A N/A N/A TR8B300
400 TR8C400 TR8C400GF TR8C400GFD TR8B400
450 N/A N/A N/A TR8B450
800 500 TR8C500 TR8C500GF TR8C500GFD TR8B500
600 TR8C600 TR8C600GF TR8C600GFD TR8B600
700 TR8C700 TR8C700GF TR8C700GFD TR8B700
800 TR8C800 TR8C800GF TR8C800GFD TR8B800
300 N/A N/A N/A TR8B300
400 TR8C400 TR8C400GF TR8C400GFD TR8B400
450 N/A N/A N/A TR8B450
800 500 TR8C500 TR8C500GF TR8C500GFD TR8B500
600 TR8C600 TR8C600GF TR8C600GFD TR8B600
700 TR8C700 TR8C700GF TR8C700GFD TR8B700
1600 800 TR8C800 TR8C800GF TR8C800GFD TR8B800
600 N/A N/A N/A TR16B600
800 TR16C800 TR16C800GF TR16C800GFD TR16B800
1600 1000 TR16C1000 TR16C1000GF TR16C1000GFD TR16B1000
1100 N/A N/A N/A TR16B1100
1200 TR16C1200 TR16C1200GF TR16C1200GFD TR16B1200
1600 TR16C1600 TR16C1600GF TR16C1600GFD TR16B1600
750 N/A N/A N/A TR20B750
800 N/A N/A N/A TR20B800
1000 TR20C1000 TR20C1000GF TR20C1000GFD TR20B1000
2000 2000 1200 TR20C1200 TR20C1200GF TR20C1200GFD TR20B1200
1500 N/A N/A N/A TR20B1500
1600 TR20C1600 TR20C1600GF TR20C1600GFD TR20B1600
2000 TR20C2000 TR20C2000GF TR20C2000GFD TR20B2000
1200 TR32C1200 TR32C1200GF TR32C1200GFD TR32B1200
3200 3200 1600 TR32C1600 TR32C1600GF TR32C1600GFD TR32B1600
2400 TR32C2400 TR32C2400GF TR32C2400GFD TR32B2400
3200 TR32C3200 TR32C3200GF TR32C3200GFD TR32B3200
1600 TR40C1600 TR40C1600GF TR40C1600GFD TR40B1600
2000 TR40C2000 TR40C2000GF TR40C2000GFD TR40B2000
4000 4000 2500 TR40C2500 TR40C2500GF TR40C2500GFD TR40B2500
3000 TR40C3000 TR40C3000GF TR40C3000GFD TR40B3000
3600 N/A N/A N/A TR40B3600
4000 TR40C4000 TR40C4000GF TR40C4000GFD TR40B4000
3200 N/A N/A N/A TR50B3200
5000 5000 4000 N/A N/A N/A TR50B4000
5000 N/A N/A N/A TR50B5000
Table 27.2 Power+™ trip unit catalog numbers
J 3 32 LSI T1 R Code Description Function
J WavePro Breaker Family
8 800A
1 1600A
2 2000A Breaker Frames
3 3200A
4 4000A
01 150A
04 400A
08 800A
16 1600A
Installed CT
20 2000A
32 3200A
40 4000A
L Long-time
S Short-time Overcurrent Protection
I Instantaneous
(none)
TARGET00 (blank insert)
T1
TARGET01 (w/o ground fault) Target Module Installed
T2 TARGET02 (with ground fault)
R Replacement unit Ordered as Replacement
Table 27.1 MicroVersaTrip Plus™ / PM™ trip unit catalog numbers
K 3 32 LSI GD Z1 PM R Code Description Function
K WavePro Breaker Family
8 800A
1 1600A
2 2000A
Frame Size
3 3200A
4 4000A
5 5000A
01 150A
04 400A
08 800A
16 1600A
Installed CT
20 2000A
32 3200A
40 4000A
50 5000A
L Long-time
S Short-time Overcurrent Protection
I Instantaneous
G Ground Fault
Ground Fault Protection
GD Ground Fault (user defeatable)
Z1 GF Zone-Selective Interlock
Z2 GF & ST Zone-Selective Interlock Optional Protection
X Switchable Inst, ST, and GF
P Protective Relays & Comm
Optional Features
M Metering & Comm
R Replacement unit Ordered as Replacement
