7.6 Excerpt from the lubricant table
The oil grade lled as standard in the factory is noted on the name plate. This oil grade should be
used preferably. Alternatives to this are listed in the following excerpt from our lubricant table.
Accessories available can be found in the F-Catalogue (Bock Ref.-No. 96023) or
on the Internet at www.bock.de.
7.5 Accessories
Type
F2 NH
3
F3 NH
3
F4 NH
3
F5 NH
3
F14/1166 NH
3
F14/1366 NH
3
F16/1751 NH
3
F16/2051 NH
3
Designation
Ref. No.
Set gaskets 08069 08070 08071 08072 08492 08493
Shaft seal 08001 08001 08008 08008 08444 08012
Valve plate set NH
3
08841 08842 08842 08843 08844 08844
Oil pump 08043 08043 08044 08044 08799 08799
Oil sump heater 08423 08424 08425 08425 08426 08426
Only use original Bock spare parts!
7.4 Spare parts recommendation NH
3
NH
3
7.7 Decommissioning
7| Maintenance
Refrigerant Bock series oil grades
Recommended alternatives
HFKW
(e.g.
R134a,
R404A/R507, R407C)
Fuchs Reniso Triton SE 55
FUCHS Reniso Triton SEZ 32
ICI Emkarate RL 32 H, S
MOBIL Arctic EAL 32
SHELL Clavus R 32
HFCKW
(e.g.
R22)
Fuchs Reniso SP 46
FUCHS Reniso, z.B. KM, HP, SP 32
SHELL Clavus SD 22-12
TEXACO Capella WF 46
NH
3
Fuchs Reniso KC 68
for ooded operation
Fuchs Reniso Synth 68
for applications using a plate
heat exchanger
-
Information on further suitable oils on request.
Close the shut-off valves on the compressor. Drain the refrigerant (it must not be discharged into the
environment) and dispose of it according to the regulations. When the compressor is depressurised,
undo the fastening screws of the shut-off valves. Remove the compressor using an appropriate hoist.
Dispose of the oil inside in accordance with the applicable national regulations.
