GEA F4 Assembly Instructions

8
D
GB
F
E
09702-09.2013-DGbF
2 | Product description
/
F 14
1166
NH
3
X
Fig. 4
2.2 Name plate (example)
2.3 Type code (example)
¹
)
X - Ester oil charge (HFC refrigerant R134a, R404A/R507, R407C)
²
)
Indication only at F14, F16
NH
3
version
Swept volume ²
)
Size
Oil charge
¹
)
Series
1
2
3
4
5
6
FX16/2051
SE55
19/28
1 Type designation
2 Machine number
3 Rotation speed minimum with a corresponding displacement
4 Rotation speed maximum with a corresponding displacement
5 ND(LP): Max. admissible operating pressure Suction side
HD(HP): Max. admissible operating pressure
High-pressure side
6 Oil type charged at factory
Observe the limit of
application diagrams!
GEA Bock GmbH
72636 Frickenhausen, Germany
