It is recommended to install
the in�k330 on the outside
edge of the hot tub, so that
it is not subject to moisture
trapped by the cover�
The back of the in�k330 should not be enclosed where
water can gather, but instead cut out�
Keypad placement
Connecting in.k330 keypad to the spa control
Vent hole on back of keypad should not be blocked�
Installation notes
Main keypad in�k330
To connect the keypad, remove the cover, then insert the in�link connector into the appropriate keypad connector
(as illustrated)� Route the cable through one of the molded strain relief channels on the bottom right side of the spa
pack (as illustrated)� Fill the remaining space with the foam gaskets supplied� Don’t forget to replace the cover and all
screws (torque to 8 in� lb max (0�9 N�m))�
