Gecko in.ye User Manual

11
Pump 2 (A2)
Voltage 120 V 240 V
Green / ground P51 P51
Black / low speed K6-P K6-P
Red / high-speed K3-P K3-P
White / common P60 P71
Blower (A4) (in.ye-5 only)
Voltage 120 V 240 V
Green / ground P48 P48
Black / line K6-P K6-P
White / common P57 P68
Pump 3 (A4) (in.yt-5 only)
Voltage 120 V 240 V
Green / ground P48 P48
Black / low speed K6-P K6-P
White / common P57 P68
Circ. pump* (A1)
Voltage 120 V 240 V
Green / ground P52 P52
Black / line K1-P K1-P
White / common P61 P72
Light (12 V AC, 1A Max.)
Voltage
Always on P34
Relay P35
Pump 1 (A3)
Voltage 120 V 240 V
Green / ground P49 P49
Black / low speed K2-P K2-P
White / common P58 P69
Ozonator* (A1)
Voltage 120 V 240 V
Green / ground P52 P52
Black / line K1-P K1-P
White / common P61 P72
Direct output 1 (in.ye-5 only)
(Floating connector)
Voltage 120 V 240 V
Green / ground P47 P47
Black / line P32 P32
White / common P56 P67
This table shows typical connections. OEMs may have a different connection scheme.
* Ozonator and circ pump can be combined on the same output via the optional splitter PP1.
A3
A4
A1
A2
OPTIONAL
PP1 SPLITTER
HIGH SPEED (RED)
LOW SPEED (BLACK)
COMMON (WHITE)
GROUND (GREEN)
LIVE (BLACK)
COMMON (WHITE)
GROUND (GREEN)
---
RED
WHITE
BLACK
GREEN
INPUT VOLTAGE
HEATING
ELEMENT
HEATER
GROUND
L1
N
L2
120V 240V
A0
120V DIRECT
K3
K4
K6
K7
K9
K10
P5
P17
P7
P22
P23
P28
P30
P33
P36
P37
P34
P18
P19
P6
P2
P3
P4
P8
P24
P29
P38
P41
P42
P45
P35
30A/480VAC TIME-DELAY
CLASS G
F2
20A/600VAC TIME-DELAY
CLASS G
30A/480VAC TIME-DELAY
CLASS G
F3
F1
F4
1
2
3
4
0.5A/250VAC
3AG FAST-ACT.
P
K1
K2
P39
P40
P43 P44
P
P
P
P
CO C1CO
P9
P10
P11
P13 P14
P15
P21
P32
P31
C
C
P12
P25
P46
P66
P47
G N
L2
P48P49P50P51P52
P53
P56
P57
P58
P59
P60
P61
P62
P67P68P69P70P71P72P73
P55
P
P76
P77
P26 P84 P16
P79
P78
P83
TRANSFORMER
LIGHT, SWITCHED
HL & TEMP.
PROBE
IN.FLO
SENSOR
MAIN KEYPAD
COMMUNICATION LINKS
LIGHT, DIRECT
High voltage accessory connections
Two options are available with Y Series spa packs for connecting high voltage accessories: 0.250” quick-connect
terminals, or AMP pins and housings.
Connection high voltage accessories: in.ye
These tabs require high-voltage accessories to have straight, non-insulated, female quick-connect terminals for all
connections, including ground. Depending on where the connections are made on the in.ye pack PCB, 120 V and
240 V accessories are supported. Refer to the following tables for correct connections. Note that all female terminals
must be correctly and completely seated on the PCB tab for proper current ratings.
Y Series connections
