page 4 SERVICE MANUAL FOR PRODUCERS SBR TYPE G-201-P00
PPUH „GECO” - G-201-P00 01,02 PRINTOUT DATE 05-01-24
IV. INSTALLATION AND CONNECTION OF G-201
1. Cut a hole with dimensions 28x70 mm in the appliance in the place marked accordingly.
2. All metal elements through which G-201 or its cables are put should be filed or protected
otherwise. I is not permitted to fix G-201 in a way which allows direct contact with water (e.g.
condensing water on the lower cover of the display), touching of evaporator outlet pipe etc. and
causes considerable changes of its temperature in comparison with air temperature (e.g. fixing
in direct vicinity of the compressor and its accessories, cooling and heated elements).
3. When G-201 is fixed, power cables should be connected in accordance with the description on
the casing. Depending on the version of G-201 some outlets may be out of use: they will not be
described on the label with description and in type description there will be ‘0’ digit: one may
not connect any cables to those outlets!!!
4. Connectors have certification for permanent load 16A !!! They are provided with fine thread and
special plates preventing cutting of cables, therefore, when lightly screwed together they will
have maximally good contact and if more force is applied, it may damage the thread. In result
the socket may be melted and there might be a short circuit!!!
5. The whole unnecessary length of cables is shortened by cutting or winding and clipping together
by special plastic bands. Cable have to be well-fastened along their whole length and may not
touch the compressor and its accessories.
6. When the appliance is connected to mains, there might be voltage in light cable regardless
whether it is switched on or off with the button therefore, the starter or the fluorescent
lamp may be replaced only when the power cable is unplugged from the socket!!!
THE SAME CONDITION IS VALID FOR ANY OTHER REPAIRS!!!
8. If there are heaters, their voltage has to be chosen in such a way that if there is a breakdown of G-
201 or of an external contactor and they are switched off permanently, there will be no
possibility of fire or destruction of the appliance. If high power heaters are used, safety
thermostat must be used on the evaporator unconditionally. This thermostat should operate on a
different basis, e.g. a mechanical thermostat.
