Page 3
version G-201-P00Kxx-M1x000
P1 – compressor R16A
6A
cos φ > 0,85
1HP 750W
P2 – Universal R16A 4A - 800W
version G-201-P00K0x-MH0000
P1 – compressor R30A
12A
cos φ > 0,85
2HP 1500W
Ia – transformer rated current.
Ib – load rated current
P – load rated power.
Notice !!!
• Total power consumed at once by appliances may not exceed 10A !!!
III. HOW TO ORDER
In the order you have to give the full name of the controller in accordance with the marking defined in
item II and the length of temperature sensors.
The following types of thermostats are available:
G - 201 –P00K00 – M1000 0
Thermostat that controls operation of the compressor
G - 201 –P00KL0 – M1200 0
Thermostat that controls operation of the compressor and lighting
G - 201 –P00K00 – M1200 0
Thermostat that controls operation of the compressor and of an additional appliance (a ventilator,
a heater or a valve (version 02))
G - 201 –P00K0B – M1000 0
Thermostat that controls operation of the compressor, provided with sound signalling
G - 201 –P00KLB – M1200 0
Thermostat that controls operation of the compressor and lighting, provided with sound
signalling
G - 201 –P00K0B – M1200 0
Thermostat that controls operation of the compressor and an additional appliance (a ventilator, a
heater or a valve (version 02)), provided with sound signalling
G - 201 –P00K00 – MH000 0
Thermostat that controls operation of the compressor with higher power
G - 201 –P00K0B – MH000 0
Thermostat that controls operation of the compressor with higher power, provided with sound signalling
