Page 4 Service Manual for Producers SCCB TYPE G-202-P00
PPUH „GECO” EDITION I PRINTOUT DATE 2014-03-27
The simplest thermostats are equipped with the following:
 1000 – compressor
 1200 - compressor and lighting system
While the mostly developed ones are equipped with the following:
 1034 - compressor, fan, heater,
 1234 - compressor, lighting system, fan, heater,
Another examples:
 1030 - compressor and fan
 1004 - compressor and heater
 1230 - compressor, lighting system, and fan
 1204 - compressor, lighting system and heater
Operating Voltage - 230V +10% -15%
Ambient Temperature - +5°C to +40°C
Relative humidity - 20% to 80%
Protection degree - IP65 on the front side of the control panel
Table 1 – Marking of relays and Outputs Loads
Output
Relays
Load
P1 – compressor
30A
8A
2HP
1500W
P2 – lighting system
16A
4A
-
750W
P3 – fan
16A
4A
1HP
750W
P4 – heater/valve
16A
8A
-
1500W
Note !!!
 Currents as specified in the Table are currents consumed by
particular equipment during normal operation and include starting
currents of this equipment !!!
 The aggregate current consumed simultaneously may not exceed 10A !!!

Geco G-202-P00 Specifications

General

Brand	Geco
Model	G-202-P00
Category	Control Unit
Language	English
