Page 11 Revision I FROM 2012-09-20
Table 2: Designation of parameters
Setting of the defrosting interval. Note !!! If you set this to
“0”, there will be no automatic defrosting, only the
manual!!! If you set this to “-01”, there will be no defrosting
at all, neither automatic nor manual!!!
Maximum defrosting time, if the evaporator does not reach
the set temperature (parameter d2). Note !!! When this
parameter is set to “-01” the duration is not limited.
Minimum compressor standstill duration
Evaporator dripping duration
Window drying duration.
NOTE!!! When this parameter is set to “0” the window
drying duration is not limited!!!
Maximum compressor operation duration
0 – means there is no test (the parameter is disabled)
Compressor standstill duration after activation of protection
set in parameter ‘c5’
Duration of showing the temperature measured just before
the defrosting, shown immediately after the defrosting
(parameter ‘c4’).
Duration of compressor operation in case of control sensor
failure
Duration of compressor standstill in case of control sensor
failure
Minimum temperature the user can set
Maximum temperature the user can set
Evaporator temperature at which the defrosting is finished
Value of chamber sensor re-scaling from the actually
measured temperature
Temperature stabilised at the window (maximum window
temperature)
Temperature hysteresis at the window.
Devices connected to the 4th relay:
00 – none
01 – fan operating together with the compressor
02 – fan operating continuously
03 – evaporator heater
04 – tray heater
Conditions for defrosting activation during the device start:
00 – start of operation without defrosting
01 – if a power outage occurred during the defrosting, the defrosting
is activated
02 – defrosting after every powering on of the device.
Door opening sensor / or additional temperature sensor option:
00 – no door opening sensor
01 – door opening sensor exists, closed at open door
