04 – four-r relay controller controlling following devices:
compressor/light/fan/heater or valve.
Keyboard of the controller’s panel with light button.
The standard input 1-2-3 enables the connection of an additional sensor whose selection
depends on the parameter r6. Depending on the setting of this parameter, we can connect the
door opening sensor (mechanical or magnetic) or an additional temperature sensor that
performs the function of a thermometer (for r6 = 3).
Operating Voltage
230V +10% -15%
Environment temperature
from +5°C to +40°C
Humidity
from 20% to 80% RH
Protection degree
IP65 front side of the panel
Temperature sensor type
NTC 2,2kΩ - range: from -40
o
C to +60
o
C
Table 1 – Marking of relays and Outputs Loads
Output
Relays
Load
P1 – compressor
30A
8A
2HP
1500W
P2 – lighting system
16A
4A
-
750W
P3 – fan
16A
4A
1HP
750W
P4 – heater/valve
16A
8A
-
1500W
Note !!!
 Currents as specified in the Table are currents consumed by
particular equipment during normal operation and include starting
currents of this equipment !!!
 The aggregate current consumed simultaneously may not exceed 10A !!!
III. ORDERING METHOD
The following parameters need to be given in the order, namely:
1. Full controller name, e.g. GC203.02
2. The length of tape connecting the executive module and keyboard panel (standard length is 1m).
3. Temperature sensors lengths(standard length: 3m or 2.5m).
