How To Use
Installation Method
1. Install the three-bar lock body (pay attention to the direction of the oblique
tongue and the direction of opening the door). See Figure Step ①; unscrew
the fixing screws of the lock body, as shown in Figure Step ②.
2. Install the front panel as shown in step ③, and then insert the square iron
and the pair of pull studs into the corresponding holes of the three-bar lock
body.
3. Install the rear panel as shown in step ④. After removing the rear panel lock
from the box, use a screwdriver to unscrew the battery cover screws as
shown in step 8. After the front and rear wirings are connected, install the
rear panel. Pay attention to : The UP↑ faces upwards. After adjusting the
rear panel, tighten the pair of pull.
4. Installation method of 7# alkaline battery: install the battery (note: pay
attention to the direction of the positive and negative electrodes when
installing the battery), as shown in the figure below;
6
1
2
3
4
+
-
+
-
+
+
-
-
8
5
7
6
