Function Identification: Charging Cradle
FRONT REAR
(1) Charging Pins
(2) Tone Adjustment
(3) LED Indicator: Battery Charge (Red = charging, Green =
fully charged)
(4) LED Indicator (Green): Audio Signal
(5) LED Indicator (Green): Power
(6) LED Indicator (Yellow): Treble enhanced
(7) LED Indicator (Blue): Bass enhanced
(8) Audio In
(9) Frequency Channel Selector (CH1 or CH2)
(10) Power ON/OFF
(11) DC In Socket
FUNCTION IDENTIFICATION
