SENDER PANEL DESCRIPTIONS
1 5V DC Power Input
Connect the included 5V DC power supply input this port. Once this has been
properly connected the power LED will become active.
2 3 RCA Component Input
Connect the component source device to this input.
3 2 RCA Analog Stereo Input
Connect the source’s analog audio to this input.
4 SPDIF Digital Audio Input
Connect the source’s SPDIF digital audio to this input.
5 Optical Digital Audio Input
Connect the source’s optical digital audio to this input.
6 Power LED Indicator
This LED will become active once the included 5V DC power supply is properly
connected.
7 RJ-45 Jack
Connect the sending and receiving units together using a TIA/EIA-568-B
terminated CAT-5, CAT-5e or CAT-6 cable. See page 10.
NOTE: Only one audio input type, digital or analog, should be connected at one time.
