gefran 1600P User Manual

st.32
xead
pa.01
pa.14
• U.CAL
• Lin
Lin
Custom linearization for main
or aux input (*)
Step 0
Step 32
......
Scale limits
Scale limits
• CuSt
Set number of parameters
in custom menu
[ 0 ... 14 ]
CuSt
Set custom “dAtA” menu
Identification code for
parameter 1
Identification code for
parameter 14
......
X X X X
x
The identification code is specified in this
position, under the parameter name
U.CAL
User calibration
U.CAL Function
1 Analogue output 1
2 Analogue output 2
3 Input 1 - custom probe 10V
4 Input 1 - custom probe 50mV
5 Input 2 - potentiometer
(*) Not available for: 16-step programmer (SPPt = 3)
programmer with control parameter groups (SPPt = 2)
input correction function enabled (SEnS + 8)
custom TC input (SEnS = 0; tyPE = 20, 21)
custom RTD input (SEnS = 1; tyPE = 4, 5)
custom PTC input (SEnS = 2 ; tyPE = 2, 3)
Start/Stop
Programmer
(0...63)
0 from enabled digital input
1 from AL1 ON
2 from AL2 ON
3 from AL3 ON
4
5 from serial line (address 0049H, bit 0)
6 from serial line (address 0049H, bit 1)
7 from keys
Reset
Programmer
(0...15)
st.00
bvtt
al.nr
sns.2
sens
+ 8 to enable HB alarm
+ 16 to enable LBA alarm
SnS.2 Signal
0 0 ... 1V
1 0.2 ... 1V
2 0 ... 10V
3 2 ... 10V
4 0 ... 20mA
5 4 ... 20mA
6 Potentiometer
7 CT 50mA ~
AL.nr Alarm 1 Alarm 2 Alarm 3
0 disabled disabled disabled
1 enabled disabled disabled
2 disabled enabled disabled
3 enabled enabled disabled
4 disabled disabled enabled
5 enabled disabled enabled
6 disabled enabled enabled
7 enabled enabled enabled
Function
0 none (key disabled)
1 MAN / AUTO select
2 LOC / REM
3 HOLD
4 Start / Stop self-tuning
5 Start / Stop autotuning
6 Set / Reset outputs OUT 1 ... OUT 4
7 Reset alarms memory
8 -
9 Instantaneous integral reset
10 START / STOP Programmer (if enabled in S.S.t.)
11 RESET Programmer (if enabled in _ _ r.t.)
Selection
of probe type
for aux input
Select number of
enabled alarms
Function of M/A keys: “
≠
”
Note: scale selection with “tYPE” code in InP.
SEnS Probe type for main input
0 Thermocouple (TC)
1 Resistance Thermometer (RTD)
2 Thermistor (PTC)
3 Voltage 0...50mV / 10...50mV
4 Current 0...20mA / 4...20mA
5 Voltage 0...10V / 2...10V
6 Custom 10V
7 Custom max 50mV
Selection of
probe type for
main input
+16 disable function in configuration menu
(only for butt parameters)
+8 to enable main input curve 4 point correction (alternative to custom linearization).
See description in “Main Input Correction Function” section.
+16 to disable averaging filter on sampled value (available from software release 3.05)
+8 to disable averaging filter on sampled value (available from
software release 3.05)
bvt.2
led.3
led.2
led.1
d.i.F.1, d.i.F.2
Function of
digital input 1
(IN1)
+ 16 for inverse logic input
+ 32 to force logic state 0 (OFF)
+ 48 to force logic state 1 (ON)
Function of
digital input 2
(IN2)
Defining SV
display function
LEd.x Function
0 none
1 MAN/AUTO (ON in manual, OFF in auto)
2 LOC/REM (ON in remote, OFF in local)
3 self-tuning enabled
4 autotuning enabled
5 IN1 repetition
6 IN2 repetition
7 enable serial dialogue
8 HOLD on
9 Error present (error code <> 0)
10 Softstart running
11 Program 0, 1, 2, 3 (LS bit)
12 Program 0, 1, 2, 3 (MS bit)
13 Programmer in START
14 Programmer in RESET
15 Programmer RUNNING
Function of “MAN” LEDs: M/A, L/R, ATUN, IN1, IN2 repetition,
event programmer, serial port enabled, errors present
+ 16 for flashing LED function
d.i.F.x Digital input function
0 none (key disabled)
1 MAN / AUTO select
2 LOC / REM
3 HOLD
4 Start / Stop programmer
5 Reset programmer
6 Software power on/off
7 Reset alarms memory
8 Select program 0, 1, 2, 3 (LS bit)
9 Select program 0, 1, 2, 3 (MS bit)
10 Advance program to end of cycle
11 Advance program to last step
12 Enable program advance
diSP Lower display (SV) function
0 SSP - setpoint enabled
1 InP.2 - aux input
2 Control output value
3 Deviation (SSP - PV)
LEd.1 (MAN), LEd.2 (AUX), LEd.3 (PRG)
bArG
bArG
0 Heat
1 Cool
2 Heat + Cool
3 PV
4 Aux input (position V2 valve)
5 Current setpoint
6 -
7 -
8 Deviation (PV-setpoint)
10%… + 10% of full scale
Bargraph
function
s.s.t.
-
r.t.
--
d.1.f.2.
d.1.f.1.
disp
+8 inverse action
+16 Autoreset enabled (Stop = program reset) (only for _S.S.t. parameter)
+16 reset from the set it puts into effect them without zero setting power (only for _ _ rt parameter)
+32 start from current value of process variable (only for _S.S.t. parameter)
980090G_MHW_1600-1800P_04-2013_ENG
