MIN limit alarm setpoint
[-19999 ... 99999]
MAX limit alarm setpoint
[-19999 ... 99999]
A
Fault Action (definition of alarm state in case
of broken probe Err, Sbr, Ebr)
Active only for the alarm related to the fault
input
Alarm 1 Alarm 2 Alarm 3
0 OFF OFF OFF
1 ON OFF OFF
2 OFF ON OFF
3 ON ON OFF
4 OFF OFF ON
5 ON OFF ON
6 OFF ON ON
7 ON ON ON
[ALL]
State of alarms 4...10 = OFF
+16 for state of alarms 4...10 = ON
SV
F
PV
Lo.AL
SV
F
PV
xi.AL
SV
F
PV
rEL
