gefran 2500

0vt Setting Outputs
This menu lets you configure the output parameters.
OUT 1 Cycle Time
(for function CO1 or CO2 only)
[1 ... 200] sec.
OUT 1
Attribute reference signal
SV
F
PV
SV
F
PV
RL.1
Function
0 OFF
1 AL1 – alarm 1
2 AL2 – alarm 2
3 AL3 – alarm 3
4 LBA – alarm LBA
5 Repeat logic input 1
6 Repeat logic input 2
7 Repeat but 1 key (if but 1 = 7)
8 AL1 or AL2
9 AL1 or AL2 or AL3
10 AL1 and AL2
11 AL1 and AL2 and AL3
12 CO1 (control output 1, 0.0...100.0%)
13 CO2 (control output 2, 0.0...100.0%)
14 CO1 (control output 1, 0.0...-100.0%)
15 CO2 (control output 2, 0.0...-100.0%)
18 AL4 – alarm 4
19 AL4 or AL5
20 AL4 or AL5 or AL6
21 AL4 or AL5 or AL6 or AL7
22 AL4 and AL5
23 AL4 and AL5 and AL6
24 AL4 and AL5 and AL6 and AL7
25 AL8 or AL9
26 AL8 or AL9 or AL10
27 AL8 and AL9
28 AL8 and AL9 and AL10
Add +32 to the values indicated in the table to obtain the denied
logic level in output (except codes 12 ...15)
OUT 2 Cycle Time
(for function CO1 or CO2 only)
[1 ... 200] sec.
OUT 2
Attribute reference signal
SV
F
PV
SV
F
PV
RL.2
OUT 3 Cycle Time
(for function CO1 or CO2 only)
[1 ... 200] sec.
OUT 3
Attribute reference signal
SV
F
PV
SV
F
PV
RL.3
OUT 4 Cycle Time
(for function CO1 or CO2 only)
[1 ... 200] sec.
OUT 4
Attribute reference signal
SV
F
PV
SV
F
PV
RL.4
ct.1
ct.2
ct.3
ct.4
A
