A
[0vt]
OUT 5
Attribute reference signal
SV
F
PV
RL.5
Function
0 OFF
1 AL1 – alarm 1
2 AL2 – alarm 2
3 AL3 – alarm 3
4 LBA – alarm LBA
5 Repeat logic input 1
6 Repeat logic input 2
7 Repeat but 1 key
8 AL1 or AL2
9 AL1 or AL2 or AL3
10 AL1 and AL2
11 AL1 and AL2 and AL3
18 AL4 – alarm 4
19 AL4 or AL5
20 AL4 or AL5 or AL6
21 AL4 or AL5 or AL6 or AL7
22 AL4 and AL5
23 AL4 and AL5 and AL6
24 AL4 and AL5 and AL6 and AL7
25 AL8 or AL9
26 AL8 or AL9 or AL10
27 AL8 and AL9
28 AL8 and AL9 and AL10
Add +32 to the values indicated in the table to obtain the denied
logic level in output
OUT 6
Attribute reference signal
SV
F
PV
RL.6
OUT 7
Attribute reference signal
SV
F
PV
RL.7
OUT 8
Attribute reference signal
SV
F
PV
RL.8
SV
F
PV
OUT W Retransmission Output Type
0 Output disabled
1 0...10V
2 2...10V
3 0...20mA
4 4...20mA
5 ±10V
tyP.An
SV
F
PV
Reference quantity
0 IN1
1 IN2
2 IN3
3 IN4
4 Fin.A (math function A)
5 Fin.b (math function b)
6 PV - Process Variable (input 1)
7 SSP - Active Setpoint
8 SP - Local Setpoint
9 DEV - Deviation (PV - SSP)
10 CO1 (control output 1)
11 CO2 (control output 2)
12 Value acquired from serial line
13 Input 1 maximum peak
14 Input 1 minimum peak
15 Input 1 peak-peak
16 Input 2 maximum peak
17 Input 2 minimum peak
18 Input 2 peak-peak
19 AL1 (limit)
20 AL2 (limit)
21 AL3 (limit)
riF.An
MIN analog repeat output scale
[scale range -19999 ÷ +99999]
SV
F
PV
MAX analog repeat output scale
[scale range -19999 ÷ +99999]
SV
F
PV
Lo.An
xi.An
SV
F
PV
Type Control Output 1 (CO1)
SV
F
PV
Type Control Output 2 (CO2)
0 Output disabled
1 0...10V (0.0 ... 100.0%)
2 2...10V (0.0 ... 100.0%)
3 0...20mA (0.0 ... 100.0%)
4 4...20mA (0.0 ... 100.0%)
5 0...10V (0.0 ... -100.0%)
6 2...10V (0.0 ... -100.0%)
7 0...20mA (0.0 ... -100.0%)
8 4...20mA (0.0 ... -100.0%)
9 -10...+10V (-100.0 ... +100.0%)
10 -10...+10V (+100.0 ... -100.0%)
Select probe power supply
0 2,5V for potentiometers
1 5V for strain gauge
2 10V for strain gauge
SV
F
PV
max. 200mA
tyP(.1
tyP(.2
ALS
Attribute reference signal OUT W
+8 reverse output
+32 only for riF.An = 0,1,2,3,4,5: output at max/min hardware
(beyond calibration limits) for input at Hi/Lo
+64 only for riF.An = 0,1,2,3,4,5: output at minimum if input is in Err,
Sbr, Ebr condition
+16 reverse output
