gefran 2500 User Manual

C
[xrd]
SV
F
PV
Select controlled variable
SPu
Number of Alarms Enabled
[0 ... 10]
SV
F
PV
AL.n
Peak Key Function
Function
0 Disabled (no function)
1 Setpoint LOC / REM
2 HOLD IN1
3 Reset memory latch
4 Selection SP1 / SP2
5 Start / Stop Self Tuning
6 Start / Stop Auto Tuning
7 Set / Reset outputs OUT 1 ... OUT 8 (for but.1 only)
8 Peak ON + (maximum) IN1
9 Peak ON - (minimum) IN1
10 Peak ON - peak
(maximum peak - minimum peak) IN1
11 Reset memory peak IN1
12 Reset alarms / peak IN1
13 Select manual local / automatic
14 Select manual remote / automatic
15 Check calibration strain-gauge IN1
(6-wire probe)
16 Calibrate strain-gauge IN1
17 U.CAL calibration (from version 1.44)
23 RESET TARE IN1 (only in manual mode and only
from 0 ... 4,2% of input scale)
34 HOLD IN2
40 Peak ON + (maximum) IN2
41 Peak ON - (minimum) IN2
42 Peak ON - peak
(maximum peak - minimum peak) IN2
43 Reset memory peak IN2
44 Reset alarms / peak IN2
47 Check calibration strain-gaugeIN2
(6-wire probe)
48 Calibrate strain-gauge IN2
55 RESET TARE IN2 (only in manual mode and only
from 0 ... 4,2% of input scale)
SV
F
PV
CAL/RST Key Function
SV
F
PV
M/A Key Function
SV
F
PV
bvt.1
bvt.3
bvt.2
D
for but3 only, adding +64 to value shown in table, disable
“back menu” function (immediate exit from configuration
menus with key combination + ).
0 IN1
1 IN2
2 IN3
3 IN4
4 Fin.A
5 Fin.b
4380291G_MHW_2500_08-2010_ENG
