gefran 2500 User Manual

Display Default CONF Description
rL.3 3 Output reference OUT3
(t.3 20 Cycle time for output OUT3
rL.4 4 Output reference OUT4
(t.4 20 Cycle time for output OUT4
rL.5 0 Output reference OUT5
rL.6 0 Output reference OUT6
rL.7 0 Output reference OUT7
rL.8 0 Output reference OUT8
typ.An 0 Type of retransmission output W
riF.An 0 Output reference W
Lo.An 0 Minimum scale output W
xi.An 3500 Maximum scale output W
typ(.1 1 Type control output CO.1
typ(.2 0 Type control output CO.2
ALS 2 Select probe power supply
Menu PAS
PAS 0 Pass-word
Pro 0 Protection code
Menu xrd
hd.1 8 Enable multiset/type process/line freq.
(tr 128 Control type
txL.1 3 Type limit control output 1
txL.2 4 Type limit control output 2
t0F.1 0 Offset for output control 1
t0F.2 0 Offset for output control 2
Fvnc.A 0 Math function A
In1.A 0 First operand of Fvnc.A
In2.A 0 Second operand of Fvnc.A
0pEr.A 0 Operator of Fvnc.A
(1.A 0 Coefficient (1.A
(2.A 0 Coefficient (2.A
(3.A 0 Coefficient (3.A
(4.A 0 Coefficient (4.A
(5.A 0 Coefficient (5.A
Fvnc.b 0 Math function b
In1.b 0 First operand of Fvnc.b
In2.b 0 Second operand of Fvnc.b
0pEr.b 0 Operator of Fvnc.b
(1.b 0 Coefficient (1.b
(2.b 0 Coefficient (2.b
(3.b 0 Coefficient (3.b
(4.b 0 Coefficient (4.b
(5.b 0 Coefficient (5.b
SPU 0 Select controlled variable
AL.n 3 Number of alarms enabled
bvt.1 8 Function key (Peak)
bvt.2 15 Function key (Cal/Rst)
bvt.3 13 Function key (M/A)
diG.1 0 Digital function input DI1
diG.2 0 Digital function input DI2
diG.3 0 Digital function input DI3
diG.4 0 Digital function input DI4
diG.5 0 Digital function input DI5
diG.6 0 Digital function input DI6
diG.7 0 Digital function input DI7
diG.8 0 Digital function input DI8
Fld 0.5 Digital filter on PV display
dS.SP 0 Select variable displayed on SV display
dS.F 7 Select variable displayed on F display
ds.PU 11 Select variable displayed on PV display
SdS.SP 17 Select alarm strings on SV display
SdS.F 18 Select alarm strings on F display
Sds.PU 19 Select alarm strings on PV display
62 80291G_MHW_2500_08-2010_ENG
62 / 77
