gefran 2500 User Manual

Display Default CONF Description
LEd.1 33 Function Led 1
LEd.2 2 Function Led 2
LEd.3 20 Function Led 3
LEd.4 13 Function Led 4
LEd.5 14 Function Led 5
brG 2 Select variable displayed on bargraph 1
Menu Lin
tyP.L 0 Type linearization
StEP.n 32 Number segments
S.00 (S.00) 0 Segment 0 low scale linearized value (Step 0)
S.01 A (S.01) 313 Segment 1 input value [1/10.000] f.s. (Step 1)
S.01 b (S.02) 31 Segment 1 linearized value (Step 2)
S.02 A (S.03) 625 Segment 2 input value [1/10.000] f.s. (Step 3)
S.02 b (S.04) 63 Segment 2 linearized value (Step 4)
S.03 A (S.05) 938 Segment 3 input value [1/10.000] f.s. (Step 5)
S.03 b (S.06) 94 Segment 3 linearized value (Step 6)
S.04 A (S.07) 1250 Segment 4 input value [1/10.000] f.s. (Step 7)
S.04 b (S.08) 125 Segment 4 linearized value (Step 8)
S.05 A (S.09) 1563 Segment 5 input value [1/10.000] f.s. (Step 9)
S.05 b (S.10) 156 Segment 5 linearized value (Step 10)
S.06 A (S.11) 1875 Segment 6 input value [1/10.000] f.s. (Step 11)
S.06 b (S.12) 188 Segment 6 linearized value (Step 12)
S.07 A (S.13) 2188 Segment 7 input value [1/10.000] f.s. (Step 13)
S.07 b (S.14) 219 Segment 7 linearized value (Step 14)
S.08 A (S.15) 2500 Segment 8 input value [1/10.000] f.s. (Step 15)
S.08 b (S.16) 250 Segment 8 linearized value (Step 16)
S.09 A (S.17) 2813 Segment 9 input value [1/10.000] f.s. (Step 17)
S.09 b (S.18) 281 Segment 9 linearized value (Step 18)
S.10 A (S.19) 3125 Segment 10 input value [1/10.000] f.s. (Step 19)
S.10 b (S.20) 313 Segment 10 linearized value (Step 20)
S.11 A (S.21) 3438 Segment 11 input value [1/10.000] f.s. (Step 21)
S.11 b (S.22) 344 Segment 11 linearized value (Step 22)
S.12 A (S.23) 3750 Segment 12 input value [1/10.000] f.s. (Step 23)
S.12 b (S.24) 375 Segment 12 linearized value (Step 24)
S.13 A (S.25) 4063 Segment 13 input value [1/10.000] f.s. (Step 25)
S.13 b (S.26) 406 Segment 13 linearized value (Step 26)
S.14 A (S.27) 4375 Segment 14 input value [1/10.000] f.s. (Step 27)
S.14 b (S.28) 438 Segment 14 linearized value (Step 28)
S.15 A (S.29) 4688 Segment 15 input value [1/10.000] f.s. (Step 29)
S.15 b (S.30) 469 Segment 15 linearized value (Step 30)
S.16 A (S.31) 5000 Segment 16 input value [1/10.000] f.s. (Step 31)
S.16 b (S.32) 500 Segment 16 linearized value (Step 32)
S.17 A (S.33) 5313 Segment 17 input value [1/10.000] f.s. (Step 33)
S.17 b (S.34) 531 Segment 17 linearized value (Step 34)
S.18 A (S.35) 5625 Segment 18 input value [1/10.000] f.s. (Step 35)
S.18 b (S.36) 563 Segment 18 linearized value (Step 36)
S.19 A (S.37) 5938 Segment 19 input value [1/10.000] f.s. (Step 37)
S.19 b (S.38) 594 Segment 19 linearized value (Step 38)
S.20 A (S.39) 6250 Segment 20 input value [1/10.000] f.s. (Step 39)
S.20 b (S.40) 625 Segment 20 linearized value (Step 40)
S.21 A (S.41) 6563 Segment 21 input value [1/10.000] f.s. (Step 41)
S.21 b (S.42) 656 Segment 21 linearized value (Step 42)
S.22 A (S.43) 6875 Segment 22 input value [1/10.000] f.s. (Step 43)
S.22 b (S.44) 688 Segment 22 linearized value (Step 44)
S.23 A (S.45) 7188 Segment 23 input value [1/10.000] f.s. (Step 45)
S.23 b (S.46) 719 Segment 23 linearized value (Step 46)
S.24 A (S.47) 7500 Segment 24 input value [1/10.000] f.s. (Step 47)
S.24 b (S.48) 750 Segment 24 linearized value (Step 48)
S.25 A (S.49) 7813 Segment 25 input value [1/10.000] f.s. (Step 49)
S.25 b (S.50) 781 Segment 25 linearized value (Step 50)
S.26 A (S.51) 8125 Segment 26 input value [1/10.000] f.s. (Step 51)
S.26 b (S.52) 813 Segment 26 linearized value (Step 52)
S.27 A (S.53) 8438 Segment 27 input value [1/10.000] f.s. (Step 53)
S.27 b (S.54) 844 Segment 27 linearized value (Step 54)
S.28 A (S.55) 8750 Segment 28 input value [1/10.000] f.s. (Step 55)
6380291G_MHW_2500_08-2010_ENG
63 / 77
