 Speed fbk loss [22] alarm with EnDat absolute encoder

Bit Value Name Description

3 0x08 MOD_INCR Cause: voltage level not correct or disturbance on signals of incremental channels A-B.

Solution: Check the connection of the the encoder-drive channels A-B, check the connection of the screen, check the encoder supply voltage, check

parameter 2102 Encoder supply, check parameter 2108 Encoder signal Vpp.

5 0x20 CRC_CKS_P Cause: SSI signals not present or disturbed cause an error on CRC

Solution: Check the connection of the clock and encoder-drive data, check the connection of the screen, check the encoder supply voltage, check

parameter 2102 Encoder supply.

8 0x100 Setup error Cause: An error occurred during setup.

Solution: Check the connection of the clock and encoder-drive data, check the connection of the screen, check the encoder supply voltage, check

parameter 2102 Encoder supply.

The following conditions occur while resetting the encoder following Speed fbk loss

Bit Value Name Description

6 0x40 ACK_TMO Cause: SSI signals not present or disturbed cause an error on CRC

Solution: Check the connection of the clock and encoder-drive data, check the connection of the screen, check the encoder supply voltage, check

parameter 2102 Encoder supply.

7 0x80 DT1_ERR Cause: Encoder has detected malfunction and signals this to the drive via bit DT1. Bits 16..31 contain the type of malfunction detected by the encoder.

Solution: See the encoder manufacturer's technical guide.

16.31

Bit =0 =1

0 Light source OK Failure (1)

1 Signal amplitude OK Erroneous (1)

2 Position value OK Erroneous (1)

3 Over voltage NO Yes (1)

4 Under voltage NO Under voltage supply (1)

5 Over current NO Yes (1)

6 Battery OK Change the battery (2)

7..15

(1) Can also be set after the power supply is switched off or on.

(2) Only for battery-buffered encoders

The following conditions occur while resetting the encoder following Speed fbk loss

Bit Value Name Description

7 0x80 DT1_ERR Cause: Encoder has detected malfunction and signals this to the drive via Error bit. Bits 16..31 contain the type of malfunction detected by the encoder.

Solution: See the encoder manufacturer's technical guide.

16.31

Type Code Description

Transmission 09h Transmitted parity bit is incorrect

0AH Checksum of transmitted data is wrong

0BH Incorrect command code

0CH Wrong number of transmitted data

0DH Illegal transmitted command argument

0FH Wrong access authorization specified

0EH Selected field has READ ONLY status

10H Data field (re) definition not executable due to field size

11H Specified address is not available in selected field
