3-2
Product Overview
Size 3
Size 4
RS485
port
Operator
Panel
TM2
terminal
TM1
terminal
Ground
terminal
Operator
Panel
RS485
port
TM2
terminal
TM1
terminal
Ground
terminal
Size 1
Size 2
