ADV50 QS, SW-PW V1.11 / CTL V2.11 11
Italiano English
Pr. Explanation Settings
Factory
Setting
NOTE
00.11 Reserved
00.12
50Hz Base Voltage
Selection
0: 230V/400V
1: 220V/380V
0
Group 1 Basic Parameters
01.00
Maximum Output
Frequency (Fmax)
50.00 to 600.0 Hz 60.00
01.01
Maximum Voltage
Frequency (Fbase)
(Motor 0)
0.10 to 600.0 Hz 60.00
220.0
01.02
Maximum Output
Voltage (Vmax)
(Motor 0)
230V series: 0.1V to 255.0V
460V series: 0.1V to 510.0V
440.0
01.03
Mid-Point Frequency
(Fmid) (Motor 0)
0.10 to 600.0 Hz 1.50
10.0
01.04
Mid-Point Voltage
(Vmid) (Motor 0)
230V series: 0.1V to 255.0V
460V series: 0.1V to 510.0V
20.0
01.05
Minimum Output
Frequency (Fmin)
(Motor 0)
0.10 to 600.0 Hz 1.50
10.0
01.06
Minimum Output
Voltage (Vmin) (Motor
0)
230V series: 0.1V to 255.0V
460V series: 0.1V to 510.0V
20.0
01.07
Output Frequency
Upper Limit
0.1 to 120.0% 110.0
01.08
Output Frequency
Lower Limit
0.0 to100.0 % 0.0
a01.09 Accel Time 1 0.1 to 600.0 / 0.01 to 600.0 sec 10.0
a01.10 Decel Time 1 0.1 to 600.0 / 0.01 to 600.0 sec 10.0
a01.11 Accel Time 2 0.1 to 600.0 / 0.01 to 600.0 sec 10.0
a01.12 Decel Time 2 0.1 to 600.0 / 0.01 to 600.0 sec 10.0
a01.13
Jog Acceleration
Time
0.1 to 600.0 / 0.01 to 600.0 sec 1.0
a01.14
Jog Deceleration
Time
0.1 to 600.0 / 0.01 to 600.0 sec 1.0
a01.15 Jog Frequency 0.10 Hz to Fmax (Pr.01.00) Hz 6.00
01.16
Auto acceleration /
deceleration (refer to
Accel/Decel time
setting)
0: Linear Accel/Decel
1: Auto Accel, Linear Decel
2: Linear Accel, Auto Decel
3: Auto Accel/Decel (Set by load)
4: Auto Accel/Decel (set by Accel/Decel Time
setting)
0
01.17 Acceleration S-Curve 0.0 to 10.0 / 0.00 to 10.00 sec 0.0
01.18 Deceleration S-Curve 0.0 to 10.0 / 0.00 to 10.00 sec 0.0
01.19
Accel/Decel Time
Unit
0: Unit: 0.1 sec
1: Unit: 0.01 sec
0
01.20
Delay Time at 0Hz for
Simple Position
0.00 to 600.00 sec 0.00
01.21
Delay Time at 10Hz
for Simple Position
0.00 to 600.00 sec 0.00
01.22
Delay Time at 20Hz
for Simple Position
0.00 to 600.00 sec 0.00
01.23
Delay Time at 30Hz
for Simple Position
0.00 to 600.00 sec 0.00
