46
3 - DESCRIPTION
PPI and PP models
All control and setup parameters are available through a digital keyboard and displayed on a backlit LCD
display.
Note: Some of the functions described in this manual might require the use of additional accessories (not
included in the supply).
Dosing capacity of the pump is determined by the number of impulses.
Dosing adjustment per single injection is linear only on values between 30% and 100%.
Raccordo tubo di mandata
Manopola spurgo
Ingresso segnale esterno
Ingresso sonda di livello
Corpo pompa
Raccordo tubo di aspirazione
Alimentazione Elettrica
Display LCD
Delivery hose fitting
Discharge knob
Pump body
Power supply
Suction hose fitting
Level probe input
External signal input
LCD display
