ENGLISH
47
4 - MAIN FUNCTIONS
All “VMS MF” metering pumps are equipped with a four-key keyboard. For convenience, at next sections
of the manual all keys will be indicated by the following symbols or described in full.
UP key ESC key
RIGHT key P key
Menu navigation
To enter programming mode press and keep “P” pressed from main menu (fig. 1):
Two-line backlit LCD
display
Scroll and increase digital
keys (units)
Key to start/ stop pump and exit from set up menu
(without saving parameters)
Enter/ exit key from set up menu (with parameters saving)
STROKES
100 SPM
password
0000
FULL
MENU
SHORT
MENU
OFF
----------------
VMS MF
R: 1.xx
WAITING
00:59
STROKES
100 SPM
PRIMING
30 Sec.
Fig. 1
