www.gemu-group.com8 / 19GEMÜ 1441
Mechanical data
Installation position: Optional
Weight: Approx. 970g
Travel sensor: Integrated for direct mounting, remote mounting possible
Travel sensor version
Detection range: 0–75 mm
Operating range: 0–75 mm
Resistance: 5 kΩ
Minimum travel sensor change: 3% (only relevant for initialization)
Correlation - Travel sensor
spindle/valve position
Retracted (top) ≙ 100% (valve open)
Extended (bottom) ≙ 0% (valve closed)
Acoustic data
Noise emission: > 85 dB (A)
Operating conditions
Ambient conditions: Use in indoor spaces
Height: Up to 2000 m (above sea level)
Relative air humidity: Maximum 95%, non-condensing
Protection class: IP 65 acc. to EN 60529
Degree of contamination: 3 (pollution degree)
Electrical data
Power supply/set value input
Supply voltage: Via set value signal
Note: A voltage of 30 V DC and an input current of 100 mA must not be exceeded. In total, a power
of 1 W must not be exceeded.
Power consumption: < 0.3 W
Short-circuit proof: Yes
Duty cycle: Continuous duty
Electrical protection
class:
III
Set value input: 4 - 20 mA
Input type: passive
Load impedance: 11.2 V DC
(corresponds to 560 Ω at 20 mA)
Accuracy/linearity: ≤ ±0.5% of full flow
Temperature drift: ≤ ±0.1% of full flow
Technical data
