13 Electrical connection
In order to address the two digital inputs "In W" and "In X" a
resistor (R=1.2KΩ±5%) must be connected in series with the
input according to the circuit diagram. The switching levels
are >11mA for a High-Signal and <8mA for a Low-Signal.
Special wiring – Use of set value input as digital input "In W"
Plug Pin Signal name Wiring
X3 1 W+, set value input
internal
external
R=1.2KΩ ±5%
Pv=1W
24 V DC voltage
e.g. PLC digital output
GND
X3 2 W-, set value input
Special wiring – Use of actual value input as digital input "In
X"
Plug Pin Signal name Wiring
X3 3 X+, actual value in-
put
internal
external
R=1.2KΩ ±5%
Pv=1W
24 V DC voltage
e.g. PLC digital output
GND
X3 4 X-, actual value input
13.8.2 Optional digital inputs
In the design with the option of two additional digital inputs,
the product has a total of four digital inputs, whereby the set
value and actual value input can continue to process ana-
logue signals.
The actual value and set value input can be used as a digital
input under the following circumstances:
Control system Operating
mode
Set value in-
put as digital
input "in W"
Actual value
input as di-
gital input "in
X"
Positioner AUTO X
Positioner MANUAL X X
Process con-
troller
AUTO
Process con-
troller
MANUAL X
Use of set value input as digital input "In W"
Plug Pin Signal name Wiring
X3 2 I-, set value input
internal
external
High level (14...28 V DC)
Low level (0...8 V DC)
GND
X1 3 GND
Use of actual value input as digital input "In X"
Plug Pin Signal name Wiring
X3 4 I-, actual value input
internal
external
High level (14...28 V DC)
Low level (0...8 V DC)
GND
X1 3 GND
Digital input 1 and 2
Plug Pin Signal name Wiring
X1 5 Digital input 1
internal
external
High level (14...28 V DC)
Low level (0...8 V DC)
High level (14...28 V DC)
Low level (0...8 V DC)
GND
X1 3 GND
X3 5 Digital input 2
