GEM 1436 cPos User Manual

www.gemu-group.com 35 / 76 GEMÜ 1436 cPos
15.2.5 Error messages during initialization
No. Error message Description Condition for the occurrence of the er-
ror
Error cause
020 Pot wrong dir Error The potentiometer has recog-
nised the wrong control func-
tion during initialization.
Parameter "CtrlFn" is set to AUTO and a
valve with control function 3 is recog-
nised, from which the actuator has
moved in the wrong direction.
Parameter "CtrlFn" is set for a fixed
control function. This set control func-
tion is not in accordance with the con-
trol function determined during initializ-
ation.
The pneumatic connections
for "CLOSED" and "OPEN" on
the valve have been switched
or the parameter "PotDir" is
set on "fall".
The wrong control function is
set.
021 Wrong function
Error
An incorrect control function
was recognised during auto-
matic initialization.
Parameter "CtrlFn" is set for a fixed
control function. This set control func-
tion is not in accordance with the con-
trol function determined during initializ-
ation.
The wrong control function is
set in the "CtrlFn" parameter.
If the parameter is set to
AUTO, the product determ-
ines the corresponding con-
trol function and stores it (not
for control function 8 - in this
case carry out manual initial-
ization or set the "CtrlFn"
parameter to "DNO").
022 Pneumatic Error During automatic initialization
of the valve a pneumatic error
was detected.
The minimum stroke was undershot
End positions cannot be reached
Leakage in the system
Check the pneumatic system
for stroke, leakage and end
positions.
023 Leakage error During automatic initialization
of the valve leakage was de-
tected.
The positioner is in initialization mode. Check the pneumatic system
for leakage and carry out ini-
tialization again.
060 TrvlSensErr error A cable break or short-circuit
in the sensor connection
(travel sensor) was detected.
Cable break or short-circuit in
the sensor connection (travel
sensor) detected.
In 1 no Signal No signal at digital input In 1 Parameter In 1 is set to OFF / ON or
Safe / ON
Connect signal to digital input
In 1
In 2 no Signal No signal at digital input In 2 Parameter In 2 is set to OFF / ON or
Safe / ON
Connect signal to digital input
In 2
In W no Signal No signal at digital input In W Parameter In W is set to OFF / ON or
Safe / ON
Connect signal to digital input
In W
In X no Signal No signal at digital input In X Parameter In X is set to OFF / ON or
Safe / ON
Connect signal to digital input
In X
15 Commissioning
