GEM 600 User Manual

39 / 44
600, 630
A
2
4
39
Leak detection hole
Vent hole
Actuator size 1
18
19
5
3
1
Actuator size 2-4
2
5
19
18
Leak detection hole
Connector 4 /
vent hole
for c.f. 1 (NC)
Connector 2 /
vent hole for c.f. 2 (NO)
A
3
4
1
39
GEMÜ 630
Connector 2
Item Name Order description
1 Valve body
Actuator size 1:
K 610... diaphragm size 10
Actuator size 2-4:
K 600... from diaphragm size 25
3 O-ring
4 Insert
5 Union nut
2 Diaphragm 600...M
18 Bolt
}
630...S30
19 Washer
39 Cap
A Actuator 9630...
}
