Gemini CDX-601 Service Manual

CDX-602（NEW）（MAIN UNIT）
PARTS LIST (MODEL NO.) (ORIGINAL MODEL)
ITEM PART NUMBER REV. Q'ty ENGLISH NAME
1 012-014A 1 PANEL CONTROL
2 031-040 1 TOP COVER
3 032-096 1 BOTTOM COVER
4 021-604 1 SUB PANEL
5 041-479 1 HEAT SINK
6 041-480 2 HEAT SINK -C
7 022-860 2 MOUNTING BRACKET
8 022-052 2 HOLDER TRANSFORMER
9
10 003-737 2 DESK DOOR
11 002-573 1 KNOB PUSH (DA)
12 003-743 1 PUSE KEY INLAY (DA)
13 002-576 1 KNOB PUSH KEY ASS'Y (C)
14 003-739 2 PR OTECTOR INLAY
15 003-711 1
HOLDER LED 3φ (7mm)
16 047-494 6 PCB SUPPORT
17 148-316 1 NAME PLATE (SMALL)
18 049-215 8 PAD FOOT
19
20 153-213 1 POLYFORM
21 196-107 3 SERIAL NO:LABEL
22 255-180 1 GIFT BOX
23 157-979 1 OWNER'S MANUAL
24 156-089 1 WARRANTY CARD
25 190-062 1 SILICA GEL
26 099-167 1 A LABEL
27 099-168 1 J LABEL
28 099-169 1 V LABEL
29 099-014 1 LABEL MADE IN TAIWAN
30 099-214 1 LABEL MADE IN CHINA
35 099-270 1 LABEL FDA
36 159-233 6 DOUBLE LABEL
37 003-581 2 SPACER (EVA)
38 160-008 1 PE BAG 85×100mm
39 160-009 1 PE BAG 230×300mm
40 160-044 1 PE BAG 160×250mm
41 160-052 1 PE BAG 650x650mm
42
43 121-002A 16 BAND-HEAD TAPPING SCREW
44 111-046A 14 BAND-HEAD TAPPING SCREW
45
46 101-043A 3 FLAT-HEAD MACHINE SCREW
47 110-172A 6 BAND-HEAD TAPPING SCREW/TWIN SCREW
48 110-174A 2 BAND-HEAD TAPPING SCREW
49 111-030 1 PAN-HEAD TAPPING SCREW
50 111-044A 4 BAND-HEAD TAPPING SCREW
51 111-057 6 FLAT-HEAD TAPPING SCREW
