Gemini CDX-601 Service Manual

CDX-602（NEW）（MAIN UNIT）
PARTS LIST (MODEL NO.) (ORIGINAL MODEL)
ITEM PART NUMBER REV. Q'ty ENGLISH NAME
52
53 131-081 3 NUT/WASHER 3mm
54 143-007 2 SPRING WASHER
55
56 170-336 MASTER CARTON
57
58
59
60
1 262-393 2 PRINTED CIRCUIT BOARD CDX802-1
2 262-291 1 PRINTED CIRCUIT BOARD CD01-4
3 262-394 1 PRINTED CIRCUIT BOARD CDX802-2
4 262-395 2 PRINTED CIRCUIT BOARD CDX802-3
5
6 074-181 2 INTEGRATED CIRCUIT BA6218
7 074-182A 2 INTEGRATED CIRCUIT BA6392FP (AT6392H)
8 074-184 2 INTEGRATED CIRCUIT PCM1717E
9 074-074 1 INTEGRATED CIRCUIT NJM7805FA
10 074-185 1 INTEGRATED CIRCUIT NJM79L05
11 074-186 2 INTEGRATED CIRCUIT NJM317
12 074-104S 2 INTEGRATED CIRCUIT NJM4558LD (M5218AL,BA15218N)
13 074-191 2 INTEGRATED CIRCUIT CXA2550N
14 074-192 2 INTEGRATED CIRCUIT CXD3068Q
15 074-183B 2 INTEGRATED CIRCUIT P87C557E8 (P83C557E4)
16
17 076-137 2 TRANSISTOR 2SA954(L) OR 2SA817(Y)
18 076-104 2 TRANSISTOR 2SA1048 OR 2SA1317
19 076-095 4 TRANSISTOR 2SC2878
20 076-002 2 SILICON TRANSISTORS 2SC945 (Q)(P)
21 076-003 SILICON TRANSISTORS OR 2SC1815 (Y)(GR)
22
23 079-027 8 RECTIFIER DIODE 1N4002 (1N4003,1N4004)
24 079-003 10 SILICON DIODE 1N4148
25 080-118 1
LIGHT EMITTING DIODE (RED) 3φ
26 001-062A 2 CD PLAYER LOADER
27 058-021 2 CRYSTAL OSCILLATOR 16.9344MHz
28 058-022 2 CRYSTAL OSCILLATOR 16MHz
29
30 092-059 2 BNC CONNECTOR
31 161-173 2 2P RCA JACK
32 092-105 1 AC INLET
33 100-069 1 FUSE 20mm UL 1A AC250V
34
35 147-028 6
CHOKE COIL 3.3µH
36
37 059-229 1 POWER TRANSFORMER EI-57×30
115/230V IN 8.3V 0 8.3V 850mA,11.7V 0 11.7V 900mA
38 059-236 1 CHOKE EE25.4 24mH
39 059-237 1 FERRIT BEAD 14×28×9H
