Gemini CDX-601 Service Manual

CDX-602（NEW）（MAIN UNIT）
PARTS LIST (MODEL NO.) (ORIGINAL MODEL)
ITEM PART NUMBER REV. Q'ty ENGLISH NAME
40
41 093-370 ☆ 1 AC CORD 18AWG×3C VW-1
42 093-371 ☆ 1 AC CORD 220V VDE
43 093-372N ☆ 1 AC CORD 230V BS
45
46
47 081-023 1 SLIDE SWITCH 2P2C UL
48 082-042F 2 TACT SWITCH
49 083-065F 1 POWER SWITCH UL
50
51 091-456 2 8P DIN MINI CONNECTOR WITH WIRE 1200mm
52 092-147 2 8P DIN MINI JACK
53 091-473 2 (RCA TYPE) CONNECTOR CORD 1M
54
55 050-029T 2
ELECTROLYTIC CAPACITOR 5φ 10µ/16V
56 050-049T 3
ELECTROLYTIC CAPACITOR 6φ 100µ/16V
57 050-146T 2
ELECTROLYTIC CAPACITOR 6φ 220µ/16V
58 050-070 1
ELECTROLYTIC CAPACITOR 10φ 470µ/16V
59 050-205 1
ELECTROLYTIC CAPACITOR 18φ×32 6800µ/25V
60 050-194 1
ELECTROLYTIC CAPACITOR 16φ 4700µ/16V
61 050-082 1
ELECTROLYTIC CAPACITOR 13φ 2200µ/16V
62
63 050-112T 2
ELECTROLYTIC CAPACITOR MINI 4φ×8 4.7µ/16V
64 050-115T 18
ELECTROLYTIC CAPACITOR MINI 4φ×8 10µ/16V
65 050-111T 2
ELECTROLYTIC CAPACITOR MINI 4φ×8 22µ/16V
66 050-113T 4
ELECTROLYTIC CAPACITOR MINI 4φ×8 1µ/16V
67
68 050-166T 4
ELECTROLYTIC CAPACITOR MINI 5φ×7 47µ/16V
69 050-174T 38
ELECTROLYTIC CAPACITOR MINI 5φ×8 100µ/10V
70 050-135T 2
ELECTROLYTIC CAPACITOR MINI 6φ×8 100µ/16V
71
72 055-062 2
METAL FILM CAPACITORS 0.1µ/275VAC
73
74 051-002T 2 CERAMIC CAPACITOR 2P/50V
75 051-020T 4 CERAMIC CAPACITOR 27P/50V
76 051-026T 14 CERAMIC CAPACITOR 47P/50V
77 051-030T 2 CERAMIC CAPACITOR 68P/50V
78 051-032T 2 CERAMIC CAPACITOR 82P/50V
79
80 051-042T 2 CERAMIC CAPACITOR 220P/50V
81 051-046T 4 CERAMIC CAPACITOR 330P/50V
82 051-050T 4 CERAMIC CAPACITOR 470P/50V
83 051-101T 4
CERAMIC CAPACITOR 0.0022µ/50V
84 051-156 1
CERAMIC CAPACITOR UL 0.0047µ/400V
85
86 054-001T 6
POLYESTER CAPACITOR 0.001µ/50V
87 054-003T 4
POLYESTER CAPACITOR 0.0015µ/50V
88 054-006T 4
POLYESTER CAPACITOR 0.0027µ/50V
89 054-011T 2
POLYESTER CAPACITOR 0.0068µ/50V
