Gemini CDX-601 Service Manual

CDX-602（NEW）（MAIN UNIT）
PARTS LIST (MODEL NO.) (ORIGINAL MODEL)
ITEM PART NUMBER REV. Q'ty ENGLISH NAME
90 054-013T 8
POLYESTER CAPACITOR 0.01µ/50V
91 054-015T 2
POLYESTER CAPACITOR 0.015µ/50V
92 054-017T 2
POLYESTER CAPACITOR 0.022µ/50V
93 054-022T 2
POLYESTER CAPACITOR 0.047µ/50V
94 054-026T 47
POLYESTER CAPACITOR 0.1µ/50V
95 054-032T 4
POLYESTER CAPACITOR 0.33µ/50V
96
97 073-504 2
RESISTOR NETWORKS 6P 5R 10KΩ
98 073-505 2
RESISTOR NETWORKS 6P 5R 4.7KΩ
99 073-508 2
RESISTOR NETWORKS 6P 5R 47KΩ
100
101 066-518 4
1/8 W CARBON FILM RESISTOR S 10Ω
102 066-526 2
1/8 W CARBON FILM RESISTOR S 22Ω
103 066-538 2
1/8 W CARBON FILM RESISTOR S 68Ω
104 066-542 14
1/8 W CARBON FILM RESISTOR S 100Ω
105 066-544 2
1/8 W CARBON FILM RESISTOR S 120Ω
106 066-546 2
1/8 W CARBON FILM RESISTOR S 150Ω
107
108 066-550 10
1/8 W CARBON FILM RESISTOR S 220Ω
109 066-551 1
1/8 W CARBON FILM RESISTOR S 240Ω
110 066-558 2
1/8 W CARBON FILM RESISTOR S 470Ω
111 066-560 3
1/8 W CARBON FILM RESISTOR S 560Ω
112 066-566 18
1/8 W CARBON FILM RESISTOR S 0Ω
113 066-554 4
1/8 W CARBON FILM RESISTOR S 330Ω
114 066-571 4
1/8 W CARBON FILM RESISTOR S 1KΩ
115 066-579 10
1/8 W CARBON FILM RESISTOR S 2.2KΩ
116 066-581 2
1/8 W CARBON FILM RESISTOR S 2.7KΩ
117 066-583 10
1/8 W CARBON FILM RESISTOR S 3.3KΩ
118 066-587 20
1/8 W CARBON FILM RESISTOR S 4.7KΩ
119 066-589 2
1/8 W CARBON FILM RESISTOR S 5.6KΩ
120 066-593 2
1/8 W CARBON FILM RESISTOR S 8.2KΩ
121
122 066-595 18
1/8 W CARBON FILM RESISTOR S 10KΩ
123 066-599 4
1/8 W CARBON FILM RESISTOR S 15KΩ
124 066-603 4
1/8 W CARBON FILM RESISTOR S 22KΩ
125 066-607 4
1/8 W CARBON FILM RESISTOR S 33KΩ
126 066-611 6
1/8 W CARBON FILM RESISTOR S 47KΩ
127 066-612 4
1/8 W CARBON FILM RESISTOR S 51KΩ
128 066-613 8
1/8 W CARBON FILM RESISTOR S 56KΩ
129
130 066-619 4
1/8 W CARBON FILM RESISTOR S 100KΩ
131 066-620 4
1/8 W CARBON FILM RESISTOR S 110KΩ
132 066-635 2
1/8 W CARBON FILM RESISTOR S 470KΩ
133 066-637 2
1/8 W CARBON FILM RESISTOR S 560KΩ
134
135 066-651 10
1/8 W CARBON FILM RESISTOR S 1MΩ
136 066-659 2
1/8 W CARBON FILM RESISTOR S 2.2MΩ
137 066-663 1
1/8 W CARBON FILM RESISTOR S 3.3MΩ
138

Gemini CDX-601 Specifications

General

Brand	Gemini
Model	CDX-601
Category	CD Player
Language	English
