geminox THI 10-50 C User Manual

- 31 -
PARTS LISTS
Rep.
Reference
Designation
1 N40.10637 PP. PIPE D.80 LENGTH 445
2 A00.23624 PE CAP N152 BPF 3-1/2
3 Y00.14139 FASTENING HOOK
4 Y00.10807 FIXING SYSTEM FOR FLUE PIPE
5 Y00.13849 BACK STOP PLATE FOR MZ (3355X80,4X1,5)
6 Y00.18233 RIGHT HAND CONSOLE (269,4X25X1,5)
7 V07.31963 WALL FASTENING ; 10-50 MODEL
8 Y90.33470 CHASSIS ; EQUIPPED THI 10-50
9 W07.31704 MOTOR; SELECTIVE VALVE WITH CABLE
10 E00.01005 O’ RING DIA DIA 29,32 X 3,6
11 L90.24635 AUTOMATIC AIR VALVE WATTS WITH ISOLATED VALVE
12 U07.34049 HEATING FLOW; GREY; THRI SEP
13 E20.03889 SEALING AFM34D 30X21X3
14 A00.19059 PLASTIC STOPPER MAL 9 WHITE
15 V90.33015 SELECTOR VALVE KIT
16 U90.28983 HEATING RETURN UNIT
17 I20.21441 MESSING SEALED CONNECTION "OLIVE" 22/1
18 V00.23999 STOP PLATE FOR HEATING AND DHW
19 V00.21491 PROTECTING RING 1
20 I20.21452 MESSING LOCK NUT 1
21 O00.32983 RIGHT FLEXIBLE PIPE NU 1/2 LG 350
22 O00.32984 RIGHT FLEXIBLE PIPE NU 1/2 LG 550
23 U07.32871 PRIMARY OUTLET PIPE
24 L50.35152 PRESSURE SENSOR HUBA TYPE 505.91540
24 V90.35156 REPLACEMENT SET OF IMIT SENSOR BY HUBA SENSOR
25 L90.24178 SAFETY VALVE
26 I20.33459 CONNECTION 1’’ -3/4’’
27 L30.33738 CIRCULATING PUMP GRUNDFOS UPS15-70/130 AO S3
28 U00.19252 SUMP INLET THRC/S GREY
29 A20.23655 SIPHONIC TRAP WITH PIPE 650 MM
30 W07.36930 CONTROL BOX ; WIRED ; PROGRAMMED
31 U07.31500 GAS INLET; EQUIPPED; 1/10 - 5/25 MODEL
32 Y90.35965 WHITE COVER THRI S/10-50C
33 T25.31875 FIXING PART; UPPER COVER
34 O00.20679 STAINLESS STEEL FLEXIBLE PIPE MALE 1/4 WITH ELBOW
35 H20.32834 FRONTPANEL GREY
36 Y07.32843 COVER + FRONTPANEL
37 V07.32114 RING FOR BOILER COVER L685
38 L20.31470 SENSOR TASSERON NTC SENSOR M5 TSA-TYPE
39 L10.10607 HONEYWELL O’RING 22 X 2,5
40 V90.33616 WIRED SIT GAS VALVE SET
41 E20.06892 SEAL AFM34 D. 18,6 X 12 2 MM THICKNESS
42 L10.33774 FLANGE G 3/4" FOR SIT VALVE
43 U07.31563 GAS INLET; COMPLETE BURNER ; 10-50C MODEL
44 U07.31498 90° ELBOW ; D.80 DRILLED
45 L20.31496 SENSOR TASSERON NTC SENSOR D10X20 10K
46 T20.00582 SIGHTGLASS PYREX D.30X5
47 B59.00692 STAINLESS STEEL WASHER 30,4X25,5X0,3
48 T40.01051 INSIDE CIRCLIPS D.30 YELLOW BICHROMATE
49 L00.16673 IGNITION ELECTRODE SHORT 74,5 AV CABLE
50 L00.12950 IONISATION PROBE (SHORT 20)
51 X00.24278 BURNER SET NG/LPG FOR THR 10-50 C
52 X00.32003 BURNER RING; REMOVABLE
53 F00.26573 GLASS BRAID RING D. 12 LG. 1070
54 V07.33783 STAINLESS STEEL BOILER SHELL THRI/THI/THISION10-50
