- 32 -
PARTS LISTS
Rep.
Reference
Designation
55 A00.03141 COLORLESS PLASTIC CAP
56 C50.31464 FAN MVL-EBM RG 128/1300-3612
57 C90.31466 IGNITION TRANSFORMER ANSTOSS ZAG 2XV 01/10
58 Y00.18234 LEFT HAND CONSOLE (269,4X25X1,5)
59 E20.35446 RING FOR THE FAN
60 I20.22440 MESSING AIR REDUCER D. 310 LP 16 (POUR REGLAGE PROPANE G 31)
60 V07.35762 PLATE HEAT EXCHANGER 35KW
61 E20.23654 EXTENSIBLE SEALING D. 18 / RED SILICONE
62 L20.32178 SURFACE TEMP. SENSOR T7335D1073B
63 U00.20366 ELBOW D. 80 45°
64 C91.03071 WIRE CARRIER
65 I20.13579 BRASS NIPPLE MAL3/4-MAL3/4(LONG)
66 L20.31471 SENSOR T7335D1024B
67 W07.32303 OUTSIDE SENSOR .QAC34/101 THRI
68 E20.03890 SEALING AFM34 D 24X17X3
69 L40.32888 DOMESTICCOLDWATERFILTERSTAINLESSSTEEL D. 18,5 EXT
70 L50.35756 FLOW LIMITER 16 L / MN
71 T40.32887 COPPER SEALING D.16 INT
72 K20.23797 3/4"-1/2 " CONNECTION ; BRASS
73 K20.32885 CONNECTION ; BRASS 3/4-1/2
74 I20.33459 CONNECTION 1’’ -3/4’’
* A00.28827 PLASTIC CAP MALE 1/4
* C09.33608 CABLE 0.960.401+CONNECT. GAS VALVE SIT 848 SIGMA
* E00.10822 EPDM LIP SEAL D. 80 75 SHORE
* E10.12503 EPDM STICKING SEAL PIPE 6/9 LENGTH 18
* E20.03901 SEALING QUALITY AFM34 D.11X4X3
* E20.24399 GASKET DN 80; BLACK POUR LES RÉFÉRENCES (U00.12053) ET (U00.20366)
* I30.31973 STOP TECHNYL D.20X19
* U00.03505 FIXING BRACKET FOR BURNER MZ/THR
* U00.08190 VERSILIC PIPE 6X10 LENGTH 800MM
* U00.18996 FLEXIBLE PIPE 4X8 LG 800 MM GAS UNIT
* V00.24191 MOUNTING KEY; HONEYWELL
* X00.05193 FIXING BRACKET FOR IONISATION PROBE
* X90.30472 IGNITION ANGLE WITH SCREW
