Gemsy GEM0311 - 机 器简介 Profile of the Machine; 规格 Specifications; 3.机头的安装 Install the Machine

型号 Type
用途 Tailor
最高转速 Sewing speed
最大针距 Stitch length
针杆行程 Needle
挑线杆行程 Thread take-up
压脚交互量 Presser foot interactive quantity
外压脚操作系统 The presser foot operating system
机针 Needle
旋梭 Hook
润滑系统 Lubrication system
剪线装置 Trimming device
倒缝装置 Reverse stitching device
2.规格 Specifications
使用说明书 Operation Instruction
0311/0611 0311/ 0611-7D2-Y
中厚料~厚料 Thick
2200rpm
9mm
38mm
73mm
2.0-5.5mm
标盘 Standard plate
DPx17 23#
1
无 ×
7mm
全自动润滑大旋梭 全自动润滑大旋梭(剪线)
1.机器简介 Profile of the machine
本系列平缝机（自动剪线）单直针，采用连杆式送料，挑线杆挑线，旋梭勾线，形成301线迹。机头加
长设计，令操作回转空间更宽敞。超长针杆行程，大互动量交替压脚，使缝厚能力更显出色。
本机采用油泵自动润滑,运转轻滑、噪音低、振动小,特别适合手箱包、汽车座垫、帐篷、沙发等皮革、
帆布、厚重装饰布、织带类物品的缝制。
T
thread take-up pick-line, Rotating hook line, form 301 stitch. Extended nose design, make operation more spacious space rotation.
Long needle bar stroke, a large amount of interaction alternating presser foot, so that Seam thickness capacity is even more
remarkable.
This machine adopts oil pump auto lubrication, smooth running light, low noise, vibration, especially for hand luggage, car
seat, tents, sofas and other leather, Canvas, heavy fabrics, sewing items like ribbon.
hick material up and down feeding (auto trimming) a single straight needle sewing machine system, using the link type feed,
有 o
无 ×
有 o
16mm
≥550mm ≥550mm
3.机头的安装 Install the machine
1)将机头支座固定在工作台凹槽四角。
2)将油盘四角搁在机头支架的中间。
3)将机头连接钩放入底板孔内，与台板的机头铰链相
嵌合，再将机头放到四只角的机头支座上。
1.Put the rubber cushion on the four corner of the tale socket
2.Hold the oil reservoir in the middle of the rubber cushion.
3.Put the head connecting hook socket into table, then connect
the head connecting hook socket and the head connecting
hook which should be on the head, and the machine head will
be put on the oil reservoir.
.
配套电机功率（W）
膝提 Knee
手提 Hand control
压脚提升高度
Press foot hoisting
height control
自动供油
