5 Order data
The order data provide an overview of standard configurations.
Please check the availability before ordering. Other configurations available on request.
Order codes
1 Type Code
Stainless steel PD valve, pneumatic F40
2 DN Code
DN 10 10
DN 15 15
DN 20 20
3 Body configuration Code
2/2-way body D
4 Connection type Code
Spigot
Spigot DIN 0
Spigot EN 10357 series B,
formerly DIN 11850 series 1
16
Spigot EN 10357 series A (formerly DIN 11850
series 2) / DIN 11866 series A
17
Spigot ASME BPE / DIN 11866 series C 59
Clamp
Clamp DIN 32676 series A 86
Clamp ASME BPE 88
5 Valve body material Code
1.4435, investment casting C3
6 Seal material Code
PTFE 5
7 Valve body adaptor Code
Adaptor for PD size 3 3
8 Control function Code
Normally closed (NC) 1
Normally open (NO) 2
9 Actuator version Code
Actuator without accessories, with standard
spring set
0N
Actuator with M12x1 thread for accessories with
standard spring set
1N
10 Bypass Code
On request
11 Surface Code
Ra ≤ 0.8 µm (30 µin.) for media wetted surfaces,
in accordance with DIN 11866 H3,
mechanically polished internal
1502
12 Seat diameter Code
20 mm H
13 Special version Code
Special version for 3A M
Order example
Order option Code Description
1 Type F40 Stainless steel PD valve, pneumatic
2 DN 15 DN 15
3 Body configuration D 2/2-way body
4 Connection type 17 Spigot EN 10357 series A (formerly DIN 11850 series 2) / DIN 11866
series A
5 Valve body material C3 1.4435, investment casting
6 Seal material 5 PTFE
7 Valve body adaptor 3 Adaptor for PD size 3
8 Control function 1 Normally closed (NC)
9 Actuator version 0N Actuator without accessories, with standard spring set
10 Bypass On request
11 Surface 1502 Ra ≤ 0.8 µm (30 µin.) for media wetted surfaces,
in accordance with DIN 11866 H3,
mechanically polished internal
12 Seat diameter H 20 mm
13 Special version M Special version for 3A
5 Order data
www.gemu-group.com
7 / 24
GEMÜ F40
