TechnicalSpecifications
VACUUM PUMP
Service Life (est.) : Unlimited (Brushless motor)
Minmum Vacuum : 50mmHg
Maximum Vacuum : 230mmHg
Suction capacity : ~4 Liters per Minute
DIMENSIONS/WEIGHT
Dimension : 5.9” (L) x 3.9” (W) x 2.1” (H) (150 mm x 99 mm x 53 mm)
Weight : 1.5 lbs (0.68 kg)
ELECTRICAL REQUIREMENT
Power : 19 VDC, 1.58A 30W (Min)
: 20 VDC (Max)
Model : MPU30B-5
Battery Type : Li-Ion rechargeable batteries
Recharge Time : ~ 3 Hours
Safety : EN55011 Class B
: UL/cUL 60601-1
: TUV/GS EN60601-1
: CE Mark (LVD)
ENVIRONMENTAL CONDITIONS
Operating Conditions : 18°C to 34°C, 65°F to 94°F
Relative Humidity : 10% to 95%
STORAGE AND SHIPPING CONDITIONS
Ambient Temperature : 0°F to 110°F, -18°C to 43°C
Relative Humidity : 10% to 95 %
PATIENT PROTECTION
Type BF
COMPLIANCE
UL 60601-1
IEC 60601-1
IEC 60601-1-2 CAN/CSA C22.2 No. 601.1

