Genelec 8030A Instruction Manual

-Max. load capacity: 15 kg
-Use four anchors per wall bracket
-Choose a position and mounting method compliant with local
-building codes and regulations
-For use only by trained installers
-For use only at proper walls with adequate anchors (see 3.)
-Not suitable are fragile walls. Beware of power supply lines and water conduits.
-In case ask an expert.
-Inspect bolted assemblies periodly
-For indoor use only
WALL MOUNT for GENELEC 8030A, 8040A, 8050A
max. load 15 kg, easy handling, adjustable direction and angle
instruction manual
4. installation
5. settings
6. dimensions safety instructions
4.a
Bolt to T-Adaptor for:
-vertical mounting
-(8030A)
-horizontal mounting
-(8040A, 8050A)
4.a
(alternative)
Remove T-Adaptor for:
-horizontal mounting
-(8030A)
-vertical mounting
-(8040A, 8050A)
-with swivel joint
5.a
Continuously adjustable up to 30°,
by fixing the upper bolted assembly
Weight: 0.9 / 1.2 kg
5.b
Pivoting attachment
around vertical axis
4.b
Replace swivel joint (with mounted GENELEC)
into wall bracket
4.c
Secure swivel joint to the wall bracket
by tightening lower bolted assembly

Genelec 8030A Specifications

General

Product color	White
Recommended usage	Other
Suitable for outdoor use	-
Tweeter	Yes
Speaker type	2-way
Number of drivers	2
Speaker placement	Tabletop/bookshelf
Audio output channels	1.0 channels
Woofer diameter (imperial)	5 \
Tweeter diameter (imperial)	0.75 \
Impedance	- Ω
Sensitivity	100 dB
Frequency range	55 - 21000 Hz
RMS rated power	80 W
Crossover frequency	3000 Hz
Total Harmonic Distortion (THD)	2 %
Connectivity technology	Wired
Cables included	AC

Weight and Dimensions

Depth	178 mm
Width	189 mm
Height	299 mm
Weight	5600 g
