English 9
AMPLIFIER SECTION
Bass amplifier output power: 50 W
Treble amplifier output power: 50 W
Long term output power is limited by driver unit
protection circuitry.
_____________________________________________
Amplifier system distortion at nominal output:
THD < 0.05 %
_____________________________________________
Mains voltage: 100-240 V AC 50-60 Hz
Voltage operating range: ±10 %
Power consumption:
Idle 3 W
Standby in ISS mode <0.5 W
Full output 60 W
SYSTEM SPECIFICATIONS
Lower cut-off frequency, –6 dB: < 47 Hz
_____________________________________________
Upper cut-off frequency, –6 dB: > 25 kHz
_____________________________________________
Accuracy of frequency response:
54 Hz – 20 kHz (± 2.0 dB)
_____________________________________________
Maximum short term sine wave acoustic output on axis
in half space, averaged from 100 Hz to 3 kHz:
@ 1 m > 104 dB SPL
_____________________________________________
Maximum long term RMS acoustic output in same
conditions with IEC weighted noise (limited by driver unit
protection circuit): @ 1 m > 96 dB SPL
_____________________________________________
Maximum peak acoustic output per pair @ 1 m distance
with music material: > 110 dB
_____________________________________________
Self generated noise level in free field @ 1 m on axis:
< 5 dB (A-weighted)
_____________________________________________
Harmonic distortion at 85 dB SPL @ 1 m on axis:
Freq: 50…100 Hz < 2 %
>100 Hz < 0.5 %
_____________________________________________
Drivers: Bass 130 mm (5 in) cone
Treble 19 mm (
3
/
4
in) metal dome
_____________________________________________
Weight: 5.0 kg (11 lb)
_____________________________________________
Dimensions: Height 299 mm (11
13
/
16
in)
(including Iso-Pod™ table stand)
Height 285 mm (11
1
/
4
in)
(without Iso-Pod™ table stand)
Width 189 mm (7
7
/
16
in)
Depth 178 mm (7 in)
CROSSOVER SECTION
Connector: Input: XLR female, balanced 10 kOhm,
pin 1 gnd, pin 2 +, pin 3 -
_____________________________________________
Input level for 100 dB SPL output at 1 m: -6 dBu
_____________________________________________
Input sensitivity control range relative to max output:
-12 dB (Constantly variable)
_____________________________________________
Crossover frequency, Bass/Treble: 3.0 kHz
_____________________________________________
Treble Tilt control operating range:
0 to –2 dB @ 15 kHz
_____________________________________________
Bass Roll-Off control: –4 dB step @ 55 Hz
_____________________________________________
Bass Tilt control operating range in –2 dB steps:
0 to –6 dB @ 100 Hz
_____________________________________________
Desktop control: –4 dB @ 160 Hz
_____________________________________________
The ‘CAL’ position is with all tone controls set to ‘off’
and the input sensitivity control to maximum (fully
clockwise).
