8
Functions on Switch Group 2
Stored / Manual Ctrl
This allows the selection between two basic methods of controlling the loudspeaker in the stand-alone
mode. “MANUAL CTRL” refers to controlling the loudspeaker using the controls on the loudspeaker’s
back panel. The “STORED” refers to using settings stored inside the memory of the loudspeaker. These
settings are made using the GLM and the GLM Control Network. There is additional functionality compared
to that offered by the room response correction switches on the back panel.
Selection Switch Function
Bass
Roll-Off
Bass Tilt Desktop Treble Tilt AES/EBU Driver
Mute
System.
Level
STORED Disabled Disabled Disabled Disabled Disabled Active Disabled
MANUAL
CTRL
Active Active Active Active Active Active Active
AES/EBU CH
This selects the audio channel(s) available on the AES/EBU cable to be reproduced by the loudspeaker.
Turning both switches on reproduces the sum of the two channels on the AES/EBU cable. Turning both
switches off has the same effect which has been done deliberately to avoid the situation where no input
channel is selected and the loudspeaker is effectively muted. When two channels are selected, 6 dB of
attenuation is automatically applied to avoid overloading the loudspeaker.
If the AES/EBU cable is operated in dual-wire mode (typically 192 kHz sampling frequency) one AES/
EBU cable carries only one audio channel. The loudspeaker detects this situation automatically and the
channel selection switches have no effect.
Driver Mute
These two switches allow you to mute the treble driver (marking TW) and bass driver (marking WF)
independently. This may be useful to diagnose if a transducer is faulty.
System Lvl
These switches allow scaling down of the loudspeaker output. The signal sent to the “Thru” output
connector is not affected. The switches are additive, for example, “–30 dB” attenuation is achieved by
turning on the “–10 dB” and “–20 dB” switches. The effect of these switches is combined with the effect of
the rotary level adjustment control. This results in total possible attenuation of 42 dB, 30 dB by the system
level switches and another 12 dB by the rotary control.
